Description

Ambu SPUR II is a single-use insufflator designed to provide users with tactile and visual feedback during resuscitation. The SEB and PVC-free composition of the bag ensures optimal compression volume with minimal mechanical resistance.
The swivel connection allows quick and easy repositioning without interrupting ventilation. It has an integrated handle for one-handed operation.
Oxygen tank for 100% concentration. The valve allows visualization of the oxygen flow.

Technical specifications :

Adult model with adult/medium mask

- Compression volume: 800 ml with one hand and 1100 ml with two hands
- Dimensions: 295 x 127 mm
- Expiratory resistance: max 0.27 kPa (2.7 cm H2O) at 50 l/min
- Dead volume: < 6 ml
- Insufflator volume: 1475 ml

Paediatric model with baby mask
- Compression volume: 450 ml
- Dimensions: 234 x 99 mm
- Expiratory resistance: max 0.3 kPa (3.0 cm H2O) at 50 l/min
- Pressure relief valve: 4.0 kPa (40 cm H2O)
- Dead volume: < 6 ml
- Insufflator volume: 635 ml

Baby model with neonatal mask
- Compression volume: 150 ml
- Dimensions: 168 x 71 mm
- Expiratory resistance: max 0.2 kPa (1.0 cm H20) at 50 l/min
- Pressure relief valve: 4.0 kPa (40 cm H2O)
- Dead volume: < 6 ml
- Insufflator volume: 220 ml

All new part numbers now include a pressure relief valve, gauge port and now have a 3 year lifespan.
For the Adult model, old reference while stocks last. Do not hesitate to ask for the new reference.

Supplied with :

- Individual resealable plastic bag colour coded by size
- Insufflator connection hose to oxygen regulator
